Radiosurgery is performed without “surgery” at all

Radiosurgery, also called stereotactic radiosurgery, is a very precise form of therapeutic radiology. Even though it is called surgery, radiosurgery does not involve actual surgery. Instead, very focused beams of radiation (gamma rays, X-rays or protons) are used to treat cancerous tissues without a surgical incision or opening.

Radiosurgery is called "surgery" because it is a one-session radiation therapy treatment that creates a result similar to an actual surgical procedure.

Types of radiosurgery and their applications

There are three types of radiosurgery. Each type uses different equipment and radiation sources. Radiosurgery types include:

Cobalt60 systems (Gamma Knife)

Cobalt60 systems use cobalt as a source for gamma rays. This type of system is commonly referred to as the Gamma Knife. The Gamma Knife is not a knife at all. It uses beams of highly-focused gamma rays to treat small- to medium-size lesions, usually in the brain. Many beams of gamma radiation join to focus on the lesion under treatment, providing a very intense dose of radiation in a safe manner.

Gamma Knife treatment generally involves these steps:

  • Head frame placement – to keep the head from moving during treatment, a box-shaped frame is attached to the head. Pins designed specifically for this purpose fasten the head frame to the skull. The head frame also is a guide to focus the gamma ray beams to the exact location of the lesion being treated.
  • Tumor location imaging – Once the head frame is in place, the exact location of the lesion to be treated will be determined using computed tomography (CT scan) or magnetic resonance imaging (MRI).
  • Radiation dose planning – After the CT or MRI scan has been completed; the radiation therapy team will determine the treatment plan. The results of the imaging scan, along with other information, will be used by a medical physicist to determine the best treatment.
  • Radiation treatment – After being positioned for the treatment, a type of helmet with many hundreds of holes in it is placed over the head frame. These holes help to focus the radiation beams on the target. Treatment will last a few minutes up to a few hours. This depends on the type and location of the area being treated. Generally, only 1 treatment session is required for a lesion.

Linear accelerator (LINAC) systems

LINAC systems use high-energy X-rays to treat large tumors or other lesions outside of the brain. Some common types of LINAC systems include CyberKnife, X-Knife, Novalis, and Peacock.

In addition to not using radioactive material to produce the radiation, LINAC systems also differ from the Gamma Knife in that the machinery moves around the patient during treatment. For this reason, LINAC systems can treat larger tumors and larger affected areas than the Gamma Knife. Areas other than the brain can be treated with a LINAC system.

Linear accelerator systems may also be used for external beam radiation therapy.

Proton beam therapy

Proton beam therapy is a type of particle beam radiation therapy. Rather than using rays of radiation, like gamma rays or X-rays, particle beam therapy uses particles, like protons or neutrons. Proton beam therapy is the most widely-used type of particle beam therapy.

Proton beam therapy is useful in treating tumors or lesions that are small and/or have an irregular shape. The radiation dose can be more closely controlled with these systems. Because the depth of the proton beam can be controlled so precisely, less damage happens to normal tissues surrounding the area under treatment.

Proton beam therapy may be used for radiosurgery procedures or for fractionated radiotherapy (several smaller doses of radiation over a certain period).

There are only a few facilities in North America that provide proton beam therapy.
